Evoloop will do all that the legendary Gibson Echoplex Digital Pro Plus (EDP) did, plus:
- true stereo
- smaller
- lower cost
- less noise
- 260x64 pixel LCD display, readable in direct sunlight
- power down loop recall
- USB and Ethernet connections
- 19" rackmount or table top
- no mechanical parts nor holes in the front pannel, so very resistent
Plus: ...it has this magical look...

so unplug the Echoplex, plug in the Evoloop and play. No need to learn new things!

BUT we want more:
- its an Evoloop and will evolve!
- we gathered loads of ideas over the last two decades of discussion on the web and at the festivals...
- the processor is 100 times more powerful than the EDP's, so we have the power to implement all that...

so far its prototype. front pannel and mechanics are working, but we restarted several times with different ARM modules. it still will take several months... the best solution would be an experienced partner!

another reason this project had to wait for over a year now is the death of Rolf Spuler which made Matthias prioize the saving of the common achievements - 30 years of hard work and an incredible result:
http://paradis-guitars.com

Sept 2015 till March 2016 the VST and Eurorack version of the Evoloop need atention

Evoloop works as a 1HE 19" rack unit or table top. To achieve this, the front is inclined and long rack ears are distatchable.

dimensions:
320x44x77mm

connections:
2 x 1/4" Stereo In
2 x 1/4" Stereo Out
1 x 1/4" EDP pedal board
1 x 1/4" Expression Pedal
USB master (for MIDI controllers)
USB slave (sound transfer with computer)
Ethernet (for Sync and software upgrade)
5V DC wall wart

front pannel:
17 touch buttons
1 touch slider
display 256x64 pixels, transflective (works with reflection in sunlight and LED backlight in the dark)

Evoloop is an initiative of Matthias Grob, the creator of the Paradis LOOP delay and Gibson Echoplex Digital Pro

partners are:

  • Pedro Itan Andrade (Brasil):front pannel hardware, touch software, layout, gantt plan
  • Philip Scheidegger (Switzerland): hardware, layout and CE test
  • Rolf Spuler (Switzerland)† - Simon Whitehurst (DE): mech design and visual effects
  • Andy Ewen + Ian @ Straight Edge and DBA (GB): manufacturing and distribution
  • Andy Butler (GB): some software contribution, consulting and testing
  • Daniel Weiss (Switzerland): consulting and possibly more...

thanks to:
Gary Hall, Keith McMillen, Kim Flint, Bob Amstadt, Timothy Crowe, Rick Walker and so many loopers who helped with hard work, good ideas, good mood and critics to get here!! (more about these people)

Raffael Dias Batista (Brasil): this site
